The electronic component desktop spot welding machine consists of a profile frame, welding transformer, water system, gas system, microcomputer resistance welding machine controller, foot switch, etc.

1. The upper electrode is pressurized by a cylinder, making pressure adjustment convenient and accurate

2. The upper electrode moves vertically up and down, and has a smooth adjustable working stroke

3. Adopting a direct solenoid valve to accelerate action response speed, significantly increase the operating speed of the upper pressure head, and reduce air flow loss

4. The descent and ascent speed of the pressurization head can be adjusted arbitrarily, easing the pressure impact on the work and reducing noise

5. The secondary conductor adopts the upper insulation method, with stable and reliable insulation performance

6. The main circuit adopts a water-cooled high-power thyristor module, which has strong output, stability, and reliability, and the water distributor can be installed outside the equipment

7. All water circuit components are made of copper and stainless steel, and are equipped with a visual water flow display to display the water flow situation

8. The operation is controlled by a manual switch, which has high production efficiency and low labor intensity

9.Equipped with a touch screen for quick switching of welding processes
